Tekla 3D Model Samples
Sample models
Fully detailed Tekla Structures models showing members, connections, stairs, ladders, platforms and grid references.
View detailsSample Erection Drawings
Large-format erection drawings: base plate layout, framing plan and elevation.
Erection drawings issued at A0 and A1 size: a column and base plate layout with anchor bolt details, a framing plan with bracing, and a building elevation. They show member marks, grid references and the information site crews need to set steel in place.
More projects
Sample Pipe Rack Package
Confidential client
A 3D assembly set and fabrication drawing set for a multi-level pipe rack structure.
View details
Sample Shop Drawings
Confidential client
Column, girder, brace and miscellaneous steel assembly drawings prepared for fabrication.
View detailsNeed Reliable Structural Steel Detailing Support?
Whether you require a complete Tekla model, fabrication drawings, erection drawings, miscellaneous steel detailing, or additional support for your existing detailing department, AB Detailing Engineering is ready to help.
Send us your project drawings, specifications, and expected delivery date. Our team will review your requirements and respond with a clear proposal.
